. PN: BPX-850-S TECHNICAL DATA Model Vita 850W Article no. BPX-850-S EAN code 0753263078636 Weight (without/with package) 1.9kg / 2.7kg AC Input 100-240V~ / 10-5A Frequency 50 - 60Hz +5V 18A +3,3V 18A +5V & +3,3V combined 100W +12V1 70.8A +12V2 - +12V1, +12V2 combined 850W P.F. >0.9 -12V 0.3A / 3.6W +5VSB 3.0A / 15W Maximum Power 850W Connectors 20+4 PIN ATX 1 8 PIN EPS (4+4) 2 8 PIN PCIe (6+2) 4 SATA 6 MOLEX 2 Cable length (mm) 20+4 PIN ATX 650 8 PIN EPS (4+4) 2 x 700 8 PIN PCIe (6+2) 2 x 500/150 SATA/MOLEX 2 x 450/150/150/150 Features ATX12V Version ATX 12V 2.53 Efficiency 80Plus Bronze Dimension (DxWxH) 140 mm x 150 mm x 86 mm PFC Active PFC (0.9) Fan 120mm FDB fan Security AFC (Automatic Fan Speed Control) OPP (Overload Protection) OTP (Over Temperature Protection) OVP (Overvoltage Protection) SCP (Short-Circuit Protection) SIP (Surge & Inrush Protection) UVP (Under Voltage Protection) OCP (Over-Current Protection)
Specificație produs
| MOLEX |
2 |
| Puterea SATA |
6 |
| 8-pin (6+2) PCI-E |
4 |
| 8-pin (4+4) ATX/ESP 12V |
2 |
| 24-pin (20+4) ATX power |
1 |
| Culoare |
Black | Чёрный |
| Dimensiune ventilatoare |
120 mm |
| Versiunea ATX |
ATX 12V 2.53 |
| Clasa de eficiență energetică |
80+ Bronze |
| Corecția factorului de putere |
Active PFC |
| Format |
ATX |
| Aplicare (Utilizare) |
PC |
| Tip |
PC Power Supply |
