Power Supply ATX 850W Chieftec Chieftronic GPU-850FC, 80+ Platinum, 140mm, Active PFC, FBl SR+LLC+DC/DC, Full Modular, Black

. TECHNICAL DATA Model PowerPlay 850W Article no. GPU-850FC EAN code 0753263076090 Weight (without/with package) 3.41kg / 3.82kg AC Input 100 - 240V / 12.0A Frequency 47 - 63Hz +5V 20A +3,3V 20A +5V & +3,3V combined 100W +12V1 70.83A +12V2 - +12V1, +12V2 combined 849.96W P.F. >0,9 -12V 0,3A / 3,6W +5VSB 3,0A / 15W Maximum Power 850W Connectors 20+4 PIN ATX 1 8 PIN EPS(4+4) 2 8 PIN PCIe (6+2) 6 SATA 9 MOLEX/FLOPPY 3/1 Cable length (mm) 20+4 PIN ATX 600 8 PIN EPS(4+4) 700/150 8 PIN PCIe (6+2) 2x 600/150 2x 600 SATA 3x 800/150/150 MOLEX/FLOPPY 700/150/150/150 Features ATX12V Version ATX 12V 2.53 Efficiency 80+Platinum Dimension (DxWxH) 160 mm x 150 mm x 87 mm PFC Active PFC Fan 140mm silent fan Security AFC (Automatic Fan speed Control) OCP (Over Current Protection) OPP (Over Power Protection) OTP (Over Temperature Protection) OVP (Over Voltage Protection) SCP (Short Circuit Protection) SIP (Surge & Inrush Protection) UVP (Under Voltage Protection)
Specificație produs
Dischetă 1
MOLEX 3
Puterea SATA 9
8-pin (6+2) PCI-E 6
8-pin (4+4) ATX/ESP 12V 2
24-pin (20+4) ATX power 1
Cablaj modular Fully Modular
Culoare Black | Чёрный
Dimensiune ventilatoare 140 mm
Tensiune de intrare 100~240 VAC
Versiunea ATX ATX 12V 2.53
Corecția factorului de putere Active PFC
Format ATX
Tip Sursă Alimentare Internal
Aplicare (Utilizare) PC
Tip PC Power Supply
Clasa de eficiență energetică 80+ Platinum
