Power Supply ATX 850W Chieftec ATMOS CPX-850FC, 80+ Gold, 120mm, Active PFC, Full Bridge LLC + DC/DC, ATX 3.0, Full Modular, Black

№ 21447
. PN: CPX-850FC TECHNICAL DATA Model ATMOS 850W Article no. CPX-850FC EAN code 0753263078407 Weight (without/with package) 1.52kg / 3.04kg AC Input 100-240V~ / 10-5A Frequency 50 - 60Hz +5V 20A +3,3V 20A +5V & +3,3V combined 100W +12V1 70.8A +12V2 - +12V1, +12V2 combined 850W P.F. >0.9 -12V 0.3A / 3.6W +5VSB 3.0A / 15W Maximum Power 850W Connectors 20+4 PIN ATX 1 8 PIN EPS (4+4) 2 8 PIN PCIe (6+2) 2 / 2 16 PIN PCIe GEN5 1 SATA 9 MOLEX 4 Cable length (mm) 20+4 PIN ATX 600 8 PIN EPS (4+4) 2 x 700 8 PIN PCIe (6+2) 2 x 700 | 700/150 16 PIN PCIe GEN5 600 SATA 3 x 550/100/100 MOLEX 550/100/100/100 Features ATX12V Version ATX 12V 3.0 Efficiency 80Plus Gold Dimension (DxWxH) 140 mm x 150 mm x 86 mm PFC Active PFC (0.9) Fan 120mm FDB fan Security AFC (Automatic Fan Speed Control) OPP (Overload Protection) OTP (Over Temperature Protection) OVP (Overvoltage protection) SCP (Short-circuit protection) SIP (Surge & Inrush Protection) UVP (Under Voltage protection) OCP (Over-Current Protection)
Specificație produs
Aplicare (Utilizare) PC
Tip PC Power Supply
Format ATX
Corecția factorului de putere Active PFC
Clasa de eficiență energetică 80+ Gold
Versiunea ATX ATX 12V 3.0
MOLEX 4
Puterea SATA 9
8-pin (6+2) PCI-E 4
8-pin (4+4) ATX/ESP 12V 2
24-pin (20+4) ATX power 1
Cablaj modular Fully Modular
Culoare Black | Чёрный
Dimensiune ventilatoare 120 mm
Tensiune de intrare 100~240 VAC
