Power Supply ATX 750W Chieftec Vega PPG-750-S, 80+ Gold, 135mm, Active PFC, Half-Bridge LLC+DC/DC, ATX 3.1, Long cables, Black

. PN: PPG-750-S TECHNICAL DATA Model Vega 750W Article no. PPG-750-S EAN code 0753263078780 Weight (without/with package) 1.96kg / 2.46kg AC Input 100-240V~ / 10-5A Frequency 50 - 60Hz +5V 20A +3,3V 20A +5V & +3,3V combined 100W +12V1 62.5A +12V2 - +12V1, +12V2 combined 750W P.F. >0.9 -12V 0.3A / 3.6W +5VSB 3.0A / 15W Maximum Power 750W Connectors 20+4 PIN ATX 1 8 PIN EPS (8/4+4) 1/1 8 PIN PCIe (6+2) 4 16 PIN PCIe GEN5 1 SATA 6 MOLEX 3 Cable length (mm) 20+4 PIN ATX 600 8 PIN EPS (4+4) 2 x 650/150 8 PIN PCIe (6+2) 2 x 600/150 16 PIN PCIe GEN5 600 SATA 2 x 400/150/150 MOLEX 400/150/150 Features ATX12V Version ATX 12V 3.1 Efficiency 80Plus Gold Dimension (DxWxH) 150 mm x 150 mm x 85 mm PFC Active PFC (0.9) Fan 135mm FDB fan Security AFC (Automatic Fan Speed Control) OPP (Overload Protection) OTP (Over Temperature Protection) OVP (Overvoltage Protection) SCP (Short-Circuit Protection) SIP (Surge & Inrush Protection) UVP (Under Voltage Protection) OCP (Over-Current Protection)
