. Performance AC Input: 200-240V / 5A Frequency: 47 - 63Hz +5V: 20A +3,3V: 20A +5V & +3,3V combined: 120W +12V 1: 53A / 636W +12V 2: N/A +12V 1 & +12V 2 combined: N/A +12V 3: N/A +12V 4: N/A +12V 3 & +12V 4 combined: N/A P.F.: >0,9 -12V: 0,3A / 3,6W +5VSB: 2,5A / 12,5W Maximum Load: 650W Native cable 20x4PIN ATX: 1 SATA: - MOLEX: - Floppy: - 4PIN 12V: - 8PIN 12V: - 8PIN (4+4) 12V: 1 6PIN PCIe: - 8PIN (6+2) PCIe: - Modular cable: 24PIN ATX: - SATA: 6 MOLEX: 3 Floppy: 1 4PIN 12V: - 8PIN 12V: - 8PIN (4+4) 12V: - 6PIN PCIe: - 8PIN (6+2) PCIe: 2 Features Spezification: ATX 12V 2.3 Form factor: PS II Efficiency: >90% Dimension (DxWxH): 160 mm x 150 mm x 87 mm PFC: Active PFC (0,9) (only 230V) Fan: 140mm silent fan Security: UVP (Undervoltage protection) OVP (Overvoltage protection) SCP (Short-circuit protection) OPP (Overload protection) OCP (Overcurrent protection) OTP (Over Temperature Protection) AFC (Automatic Fanspeed Control) SIP (Surge & Inrush Protection) Warranty: 24 Month
Specificație produs
| Tip Sursă Alimentare |
Internal |
| Aplicare (Utilizare) |
PC |
| Tip |
PC Power Supply |
| Format |
ATX |
| Corecția factorului de putere |
Active PFC |
| Clasa de eficiență energetică |
80+ Gold |
| Versiunea ATX |
ATX 12V 2.3 |
| Dischetă |
1 |
| Puterea SATA |
6 |
| 8-pin (6+2) PCI-E |
2 |
| 6-pin PCI-E |
-- |
| 8-pin ESP 12V |
-- |
| 8-pin (4+4) ATX/ESP 12V |
1 |
| 4-pin ATX 12V |
-- |
| 24-pin (20+4) ATX power |
1 |
| Cablaj modular |
Semi-modular |
| Culoare |
Black | Чёрный |
| Dimensiune ventilatoare |
140 mm |
| Tensiune de intrare |
200~240 VAC |
| MOLEX |
3 |
