Power Supply ATX 1250W Chieftec POLARIS PPS-1250FC, 80+ Gold, 140mm, Active PFC, Half-Bridge LLC+DC/DC, Full Modular, Black

. Model POLARIS 1250W Article no. PPS-1250FC EAN code 753263077516 Weight (without/with package) 2.7kg / 3.5kg AC Input 100-240V / 15-8A Frequency 50 - 60Hz +5V 22A +3,3V 22A +5V & +3,3V combined 120W +12V1 104.1A +12V2 - +12V1, +12V2 combined 1250W P.F. >0,9 -12V 0,3A / 3,6W +5VSB 3.0A / 15W Maximum Power 1250W Connectors 20+4 PIN ATX 1 8 PIN EPS (4+4) 2 8 PIN PCIe (6+2) 6 SATA 12 MOLEX 4 Cable length (mm) 20+4 PIN ATX 650 8 PIN EPS (4+4) 2 x 650 8 PIN PCIe (6+2) 3 x 600/100 SATA 3 x 550/100/100/100 MOLEX/FLOPPY 550/100/100/100 Features ATX12V Version ATX 12V 2.3 Efficiency 80+Gold Dimension (DxWxH) 160 mm x 150 mm x 86 mm PFC Active PFC Fan 140mm silent fan Security AFC (Automatic Fan speed Control) OCP (Over Current Protection) OPP (Over Power Protection) OTP (Over Temperature Protection) OVP (Over Voltage Protection) SCP (Short Circuit Protection) SIP (Surge & Inrush Protection) UVP (Under Voltage Protection)
Specificație produs
Tensiune de intrare 100~240 VAC
Clasa de eficiență energetică 80+ Gold
Versiunea ATX ATX 12V 2.53
Corecția factorului de putere Active PFC
Format ATX
Tip Sursă Alimentare Internal
Aplicare (Utilizare) PC
Tip PC Power Supply
Dimensiune ventilatoare 120 mm
Culoare Black | Чёрный
24-pin (20+4) ATX power 1
Cablaj modular Fully Modular
MOLEX 4
Puterea SATA 12
8-pin (6+2) PCI-E 6
8-pin (4+4) ATX/ESP 12V 2
