// CPU - AMD AM4 Socket - Supports AMD AM4 Socket Ryzen™ 3000, 4000 G-Series and 5000 Series Desktop Processors *Not compatible with AMD Ryzen™ 5 3400G and Ryzen™ 3 3200G. Chipset - AMD B550 Memory - Dual Channel DDR4 Memory Technology - 2 x DDR4 DIMM Slots AMD Ryzen series CPUs (Matisse) support DDR4 4600+(OC) / 4533(OC) / 4466(OC) / 4400(OC) / 4333(OC) / 4333(OC) / 4266(OC) / 4200(OC) / 4133(OC) / 4000(OC) / 3866(OC) / 3800(OC) / 3733(OC) / 3600(OC) / 3466(OC) / 3200 / 2933 / 2667 / 2400 / 2133 ECC & non-ECC, un-buffered memory* Graphics - Three graphics output options: D-Sub, DVI-D and HDMI - Supports Triple Monitor - Supports HDMI 2.1 with max. resolution up to 4K x 2K (4096x2160) @ 60Hz - Supports DVI-D with max. resolution up to 1920x1200 @ 60Hz - Supports D-Sub with max. resolution up to 1920x1200 @ 60Hz Audio - 7.1 CH HD Audio (Realtek ALC887 Audio Codec) LAN - PCIE x1 Gigabit LAN 10/100/1000 Mb/s - Realtek RTL8111H Slots - 1 x PCI Express 4.0 x16 Slot (PCIE1: x16 mode)* - 1 x PCI Express 3.0 x1 Slot Storage - 4 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1 and RAID 10), NCQ, AHCI and Hot Plug - 1 x Hyper M.2 Socket, supports M Key type 2242/2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen4x4 (64 Gb/s) (with Matisse) or Gen3x4 (32 Gb/s) (with Renoir)* USB - 6 x USB 3.1 Gen1 Ports (2 Front, 4 Rear) - 6 x USB 2.0 Ports https://www.asrock.com/mb/AMD/B550M-HDV/index.asp#Overview
Specificație produs
| Porturi USB 3.x | 1 x USB 3.2 Gen1 (Supports 2 USB 3.2 Gen1 ports) |
| Porturi USB 2.0 | 2x USB 2.0 (Support 4 USB Ports) |
| USB Type-C | -- |
| USB 3.x Type-A | 4x USB 3.2 |
| USB 2.0 Type-A | 2x |
| RAID | RAID 0, RAID 1, RAID 10 |
| Conectori SATA | 4x SATA 6Gb/s |
| Suport slot M2 # 4 | -- |
| Suport slot M2 # 3 | -- |
| Suport slot M2 # 2 | -- |
| Conector Thunderbolt | -- |
| Suport slot M2 # 1 | M2: SATA3 & PCIe Gen4 x4 (64 Gb/s) |
| Bluetooth | -- |
| Controler Ethernet #2 | -- |
| Controler Wi-Fi | -- |
| Controler Ethernet #1 | Gigabit Ethernet (Realtek RTL8111H) |
| SPDIF port ieșire | -- |
| Porturi | HD Audio Jacks: Line in / Front Speaker / Microphone |
| Chipset audio | 7.1 Ch HD Audio, Realtek ALC887 |
| DVI | 1x DVI-I |
| DisplayPort | -- |
| HDMI | 1x HDMI |
| Capacitate max. Totală RAM | 64GB |
| Frecvență memorie | 2133 MHz |
| Sloturi memorie | 2x DIMM |
| Procesoare suportate | Ryzen series (3000/4000/5000) |
| Chipset | AMD B550 |
| Socket | AM4 |
| Factor de formă a plăcii de baza | Micro-ATX |
| Tip | Mainboard |
| Tip Memorie | DDR4 SDRAM |
