// CPU - Supports AMD AM4 Socket Ryzen™ 3000, 4000 G-Series and 5000 Series Desktop Processors* Chipset - AMD A520 Memory - Dual Channel DDR4 Memory Technology - 2 x DDR4 DIMM Slots - DDR4 4600+(OC) / 4533(OC) / 4466(OC) / 4400(OC) / 4333(OC) / 4333(OC) / 4266(OC) / 4200(OC) / 4133(OC) / 4000(OC) / 3866(OC) / 3800(OC) / 3733(OC) / 3600(OC) / 3466(OC) / 3200 / 2933 / 2667 / 2400 / 2133 ECC & non-ECC, un-buffered memory* - Max. capacity of system memory: 64GB** Graphics Three graphics output options: D-Sub, DVI-D and HDMI - Supports Triple Monitor - Supports HDMI 2.1 with max. resolution up to 4K x 2K (4096x2160) @ 60Hz - Supports DVI-D with max. resolution up to 1920x1200 @ 60Hz - Supports D-Sub with max. resolution up to 1920x1200 @ 60Hz Audio - 7.1 CH HD Audio (Realtek ALC887 Audio Codec) LAN - PCIE x1 Gigabit LAN 10/100/1000 Mb/s - Realtek RTL8111H Slots - 1 x PCI Express 3.0 x16 Slot (PCIE2: x16 mode)* - 1 x PCI Express 3.0 x1 Slot Storage - 4 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1 and RAID 10), NCQ, AHCI and Hot Plug - 1 x Ultra M.2 Socket, supports M Key type 2242/2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4 (32 Gb/s) USB - 6 x USB 3.1 Gen1 Ports (2 Front, 4 Rear) - 6 x USB 2.0 Ports https://www.asrock.com/mb/AMD/A520M-HDV/index.asp#Overview
Specificație produs
| Suport slot M2 # 2 |
-- |
| Suport slot M2 # 1 |
M2: SATA3 & PCIe Gen3 x4 (32 Gb/s) |
| Bluetooth |
-- |
| Controler Wi-Fi |
-- |
| Controler Ethernet #2 |
-- |
| Controler Ethernet #1 |
Gigabit Ethernet (Realtek RTL8111H) |
| SPDIF port ieșire |
-- |
| Porturi |
HD Audio Jacks: Line in / Front Speaker / Microphone |
| Suport slot M2 # 3 |
-- |
| Chipset audio |
7.1 Ch HD Audio, Realtek ALC887 |
| DisplayPort |
-- |
| HDMI |
1x HDMI |
| Capacitate max. Totală RAM |
64GB |
| Frecvență memorie |
3200 MHz |
| Tip Memorie |
DDR4 SDRAM |
| Sloturi memorie |
2x DIMM |
| Procesoare suportate |
Ryzen series (3000/4000/5000) |
| Chipset |
AMD A520 |
| DVI |
1x DVI-I |
| Socket |
AM4 |
| Suport slot M2 # 4 |
-- |
| RAID |
RAID 0, RAID 1, RAID 10 |
| Conectori SATA |
4x SATA 6Gb/s |
| Porturi USB 3.x |
1 x USB 3.2 Gen1 (Supports 2 USB 3.2 Gen1 ports) |
| Porturi USB 2.0 |
2x USB 2.0 (Support 4 USB Ports) |
| Conector Thunderbolt |
-- |
| USB Type-C |
-- |
| USB 3.x Type-A |
1x |
| USB 2.0 Type-A |
2x |
| Factor de formă a plăcii de baza |
Micro-ATX |
| Tip |
Mainboard |
